ScalerX India LLP is Scaler India's advanced air–liquid infusion and mixing system engineered to generate nano and micro bubbles for enhanced aeration, oxidation, and gas transfer. It integrates seamlessly into AOP, DAF, STP, ETP, RO, and industrial oxidation processes.
ScalerX India LLP is Scaler India's advanced air–liquid infusion and mixing system engineered to generate nano and micro bubbles for enhanced aeration, oxidation, and gas transfer.
It integrates seamlessly into AOP, DAF, STP, ETP, RO, and industrial oxidation processes, providing exceptional gas dissolution and reaction efficiency.
Generates bubbles smaller than 200 nm, providing maximum surface area for superior gas transfer and reaction efficiency in water treatment processes.
Advanced hydrodynamic design creates intense turbulence, accelerating chemical reactions up to 5x faster than conventional mixing systems.
Patented anti-clogging mechanism ensures continuous operation without maintenance downtime, even with high-solids water.
Built with SS304/316 stainless steel for exceptional durability, corrosion resistance, and long-term performance in harsh industrial environments.
Designed for maximum efficiency with power consumption as low as 0.1–0.15 kWh per cubic meter of water treated, reducing operational costs.
Flexible architecture allows for easy capacity expansion and seamless integration with existing water treatment systems.
In AOP systems for maximum oxidation efficiency
Compared to standard injectors and mixing systems
Improved separation efficiency in dissolved air flotation
In biological wastewater treatment systems
Per module for space-efficient installation
Continuous use with minimal downtime
Produces bubbles smaller than 200 nm for maximum surface area and superior gas transfer efficiency
Advanced reaction zone accelerates chemical and biological processes 5× faster
Zero choke technology ensures continuous operation without clogging or maintenance downtime
SS304/316 stainless steel construction for durability and corrosion resistance
Low power consumption of only 0.1–0.15 kWh per cubic meter of water treated
Scalable architecture for easy capacity expansion and system integration
| Model | Recommended Water Flow (m³/hr) | Nominal Air Infusion (Nm³/hr / LPM) | Air : Liquid Ratio (typ.) | Application |
|---|---|---|---|---|
| Scaler X-1 | 1 – 2 | 0.06 / 1 | 1.3 | Pilot, Lab & Small Recycle Systems |
| Scaler X-2 | 3 – 5 | 0.12 / 2 | 1.4 | Medium STP / ETP Units |
| Scaler X-3 | 6 – 10 | 0.24 / 4 | 1.45 | Compact DAF / AOP Plants |
| Scaler X-5 | 10 – 15 | 0.36 / 6 | 1.5 | Industrial AOP + DAF Systems |
| Scaler X-10 | 20 – 30 | 0.72 / 12 | 1.5 | Centralized Treatment Systems |
| Scaler X-15 | 30 – 50 | 1.08 / 18 | 1.6 | Large Flow Systems / Industrial Aeration |
| Scaler X-20 | 40 – 60 | 1.44 / 24 | 1.7 | Mid-High Capacity Industrial / Modular AOP + DAF Units |
| Scaler X-30 | 50 – 100 | 2.16 / 36 | 1.8 | High-Capacity Industrial Plants / AOP Modules / Central DAF Units |
Enhanced aeration and oxidation for ETP/STP systems
Superior ozone and hydroxyl radical generation for contaminant destruction
Improved bubble generation for efficient solids separation
Enhanced ozone transfer for water disinfection and oxidation
Efficient oxygen transfer for biological treatment processes
Crystal clear water with reduced chemical usage
High-purity water treatment for process and product water
Precise gas-liquid reactions for manufacturing processes
Local engineering expertise combined with global quality standards
Field-tested performance with documented case studies
Built for 24/7 operation with minimal maintenance requirements
Compatible with existing systems and ready for global deployment
Contact our engineering team for a customized solution. Get a free technical assessment and quotation for your specific requirements.
